LOAD CAPACITY
max. 8000 kg
LIFT HEIGHT
max. 8000 mm
TRAVEL SPEED
max. 32.7 km/h
ENGINE OUTPUT
LPG 58.7 kW
DSL 55.4 kW
STACKING WIDTH
min. 5250 mm
The driver’s workstation is designed ergonomically and customized to the driver’s requirements. Due to the excellent view in all directions, the driver can fully focus on the job. This leads to optimal conditions for high productivity during the entire operating period.
The power behind the punch
Proven PSI LPG engine (4.3 L, 58.7 kW)
- Low-fuel high-performance industrial engine
Modern Deutz diesel engine (3.6 L, 55.4 kW)
- Meets emissions class IIIB
- Direct fuel injection with high peak torque
- With the installed diesel oxidation catalyst (DOC), there is no machine downtime. The exhaust after treatment is done during the operation. Alternative systems with DPF (diesel particulate filter) require a regeneration process, which means truck downtime during the operation
- Two primary cylinders in triplex uprights ensure a wide vision window with maximum view
- Robust 6-roller fork carriage
- Adjustable canted load rollers
- Optimum load distribution and low clearance
